Full Description

This Standard presents a mathematical definition of geometrical dimensioning and tolerancing consistent with the principles and practices of ASME Y14.5-2009, enabling determination of actual values. While the general format of this Standard parallels that of ASME Y14.5-2009, the latter document should be consulted for practices relating to dimensioning and tolerancing for use on engineering product definition and in related documentation.

Product Details

Published: 08/31/2020 ISBN(s): 9780791873038 ANSI: ANSI Approved Number of Pages: 101 File Size: 1 file , 4.5 MB Redline File Size: 2 files , 15 MB
