Full Description

This paper presents the reasoning and justification for using the B2' = (2/3)*B2 in Paragraphs NB-3656(b) and NC/ND-3655(b) of ASME Section III. Concern has been expressed that since the tests that form part of the basis for setting B2' = (2/3)*B2 were conducted at ambient temperature, the effect of dynamic strain aging of carbon steels could reduce the seismic margins at temperatures in excess of 300F (150C). In response to this concern, the authors prepared this paper as a team working under the Piping Seismic Task Group. This paper demonstrates that: For typical carbon steel under seismic strain rate loading, at elevated temperature [(above 300F (150C)] and at stress levels permitted by the alternative Code equation [NB-3556(b)(2) and NB-3556(b)(3)], the margin to failure is at least 1.5, as recommended by Dr. R.P. Kennedy. Thus, the use of B2' = (2/3)*B2 results in a component with acceptable margin. The B2 index itself is a conservative estimate of the stress in the component, both from the method of application in the Code (use for prediction of seismic stresses) and from the value itself. Thus, the use of B2' = (2/3)*B2 results in a component with acceptable margin.

Product Details

Published: 11/06/2009 ISBN(s): 9780791831823 Number of Pages: 42 File Size: 1 file , 2.3 MB
