ASME Y32.2.3-1949 (R1999) [ Withdrawn ] Graphic Symbols for Pipe Fittings, Valves and Piping

standard by ASME International, 01/01/1949

More details

In stock

$65.25

-55%

$145.00

More info

Full Description

This standard has been developed for use on drawings. By the use of these symbols on their plans, architects, engineers, and contractors will have a standard method of indication for pipe fittings, valves piping and allied items. Previously designated ANSI Z32.2.3.

Product Details

Published: 01/01/1949 ANSI: ANSI Approved Number of Pages: 11
